Description

Working speed: <= 70m/min. Working temperature: -30°C / +80°C.

The "DT" tensioner discs are made of XC38 steel mounted with sealed and life-lubricated zinc-plated bichromated bearing. The "DT" tensioner discs can be delivered with axis + nut + lock nut on simple request.

The "DTP" tensioner discs dimensionally identical to the type "DT" are made of plastic PA 6-load 30% fibreglass.

Product Details
DT05B23
9 Items

Specific References

  • DOM-disquetendeur
Attachments

ELEMENTS TENDEURS TYPE DT et DTP

Download (548.18KB)
19 people are viewing this right now
DOM
DT05B23
9 Items
€5.94
Tax excluded
order: 1
Ø Ext (mm): 62.15
ETB-Roulement: 203 KRR
Material: Acier
ETB-F (mm): 40
ETB-H (mm): 18.3
ETB-J (mm): 12
Not: 8
NOTICE: 05B1
Z: 23
ETB-Ø Prim (mm): 58.75
ETB-B1: 2.8
ETB-D1 (mm): 16+0.26 +0.13
Quantity
Add to Wishlist
Add to Compare
Last items in stock

Hurry up! Only 9 item(s) left in Stock!
Idler Sprocket,  TENSIONERS

Choose product attributes:

 Product is available
 Product available on plateform

*Prix HT hors frais d’envoi

Ref. order Material Z Ø Ext (mm) Not NOTICE Unit price Weight Avail. Buy
DT05B23 1 Acier 23 62.15 8 05B1 0.1 kg
DT06B21 2 Acier 21 68 9.525 06B1 0.1 kg
DT081.20 3 Acier 18 78.9 12.7-3.3 081.1 0.2 kg
DT081.18 3 Acier 18 78.9 12.7-3.3 081.1 0.2 kg
DT083.18 4 Acier 18 78.9 12.7-4.88 083.1 0.2 kg
DT08B14 5 Acier 14 61.8 12.7 08B1 0.15 kg
DT08B16 6 Acier 16 69.5 12.7 08B1 0.15 kg
DT08B18 7 Acier 18 77.8 12.7 08B1 0.15 kg
DT10B14 8 Acier 14 78 15.8 10B1 0.2 kg
DT10B15 9 Acier 15 83 15.8 10B1 0.25 kg
DT10B16 10 Acier 16 88 15.8 10B1 0.3 kg
DT10B17 11 Acier 17 93 15.8 10B1 0.35 kg
DT12B12 12 Acier 12 81.5 19.05 12B1 0.25 kg
DT12B13 13 Acier 13 87.5 19.05 12B1 0.3 kg
DT12B14 14 Acier 14 93.6 19.05 12B1 0.4 kg
DT12B15 15 Acier 15 99.8 19.05 12B1 0.45 kg
DT16B12 16 Acier 12 109 25.4 16B1 0.7 kg
DT20B13 17 Acier 13 147.8 31.75 20B1 1.6 kg
DTP06B21 18 Plastique 21 68 9.525 06B1 0.1 kg
DTP08B16 19 Plastique 16 69.5 12.7 08B1 0.1 kg
DTP08B18 20 Plastique 18 77.8 12.7 08B1 0.1 kg
DTP10B15 21 Plastique 15 83 15.8 10B1 0.1 kg
DTP12B13 22 Plastique 13 87.5 19.05 12B1 0.1 kg
DTP12B15 23 Plastique 15 99.8 19.05 12B1 0.1 kg
Total: 0,0
All prices with tax excluded.
Tax rate: 20,0%.
