HTD® 14M170 pilot-bore pulley
  • New
HTD® 14M170 pilot-bore pulley

HTD® 14M170 pilot-bore pulley

Description

The HTD® 14M170 timing pulley matches a 14M-profile synchronous belt with a nominal width of 170 mm and a 14 mm pitch.

Comes in 28 to 216 tooth versions, some made to order.

Match this width to the intended belt, then check tooth count, diameter and final bore.

Product Details
112-14M170MA

Specific References

  • 8054652089212
  • DOM-poulie-MA-14m170
25 people are viewing this right now
DOM
112-14M170MA
€0.00
Tax excluded
order: 1074
Material: fonte
CHI-Pièce: Poulie
CHI-Version poulie: 14M-170
CHI-type3: 112-14M170
Teeth: 112
Execution: 12
Dp: 499,11
De: 496,32
Df flange: -
Dm: 265
CHI-Di: 457
CHI-F: 187
N° flange: -
CHI-Flasque: non
CHI-M: 7
CHI-Moyeu amovible: MA
CHI-S: 127
CHI-FORO MAX: 125
CHI-BUSS.: 5050
Quantity
Add to Wishlist
Add to Compare

Sorry, no items left.
PULLEYS,  HTD® Pulleys with Removable Hub,  HTD® 14M Timing Pulleys with pilot-bore

Choose product attributes:

 Immediate stock
 Platform stock

*Prix HT hors frais d’envoi

Ref. order Teeth Execution Dp De Df flange Dm Material N° flange Unit price Weight Avail. Buy
38-14M170MA 1065 38 3F 169,34 166,6 183 - Acier 172
€0.00
12.695 kg
40-14M170MA 1066 40 3F 178,25 175,49 188 - Acier 162
€0.00
14.565 kg
44-14M170MA 1067 44 3F 196,08 193,28 211 - Acier 175
€0.00
17.366 kg
48-14M170MA 1068 48 3F 213,9 211,11 226 - Acier 180
€0.00
21.313 kg
56-14M170MA 1069 56 3F 249,55 246,76 256 - fonte 182
€0.00
28.5 kg
80-14M170MA 1072 80 11 356,51 353,71 - 230 fonte -
€0.00
48.5 kg
90-14M170MA 1073 90 12 401,07 398,28 - 230 fonte -
€0.00
53.5 kg
112-14M170MA 1074 112 12 499,11 496,32 - 265 fonte -
€0.00
74.5 kg
144-14M170MA 1075 144 12 641,71 638,92 - 265 fonte -
€0.00
91 kg
168-14M170MA 1076 168 12 748,66 745,87 - 265 fonte -
€0.00
116 kg
